- Voltage Tolerance: DC Operation: +10/-15% of nominal.
- Load (Burden): Maximum of 1 VA for all voltages
- Setting Accuracy: Maximum Setting (Adjustable): +5%, -0%; Minimum Setting (Adjustable): +0%, -50%; Fixed Time Delay: +2% or 50ms, whichever is greater
- Repeat Accuracy (Constant Voltage & Temperature): +0.1% or + 0.04 seconds, whichever is greater
- Reset Time: 40ms
- Output Contacts: Solid State 1A Continuous, 10A Inrush @ 65o C
- Life: No predictable failure if used within operating parameters.
Leakage Current (OFF-State): <10 uA @ 125VDC
Minimum Load Current: 0mA
Effective Voltage Drop (ON-State): Maximum 0.69V @ 1A for all voltages
- Temperature: -28o to 65oC (-18o to 149oF)
