TIME DELAY RELAYS

Macromatic offers a wide variety of Time Delay Relays (sometimes referred to as time relays or timers). Four types of mounting configurations for time delay relays are available. Each time relay series has a variety of functions, time-setting methods & output configurations. Pick the exact time delay relay product to meet your requirements.

Largest Selection of Time Delay Relays in the Industry

Time Delay Relays with plug-in enclosures use 8- or 11-pin octal sockets that mount on 35 mm DIN-rail or to a panel with two screws. Encapsulated designs are compact, low-cost, and resistant to the effects of harsh environments. DIN-rail mounted timers are easily installed, saving space and installation costs. Relays with DIN-16 mounting can be door mounted for easy access without opening the door. If you need help picking the right relay, contact us.



PLUG-IN

The time delay on TR-5 and TR-6 Series Relays is analog set. TD-7 Series Relays use pushbutton thumbwheels to set the time range, time delay, and function. TD-8 Series Relays use two 10-positon DIP-switches for programming.

ENCAPSULATED

THR-1 and THR-3 Series have 10A SPDT relay output. THS-1, THL-1 and THL-8 have 1 A Normally Open solid-state output. A 10-position DIP-switch is used to program the THL-8 Series uses. Time delay is analog set on other encapsulated series.



17.5 MM WIDE, DIN-RAIL

Choose from single (TE-6 Series) or multi-function (TE-881 Series). These compact relays mount on 35 mm DIN-rail to conserve space and reduce installation time.

30 AMP ENCAPSULATED

High Amp TH4 Series effectively and economically control heavy loads without a separerate contactor. The relays combine time-based control with high amperage switching capacity in compact 2” x 3” encapsulated enclosures.

1/16 DIN MOUNTING

Relays with 1/16 DIN style enclosures include an adapter for panel or surface mounting. TAD Series use push-button thumbwheels to set the time delay shown on a LED display. TAA Series use a large dial to set the time delay.
